Voltage: 12V/24V
Power: 60(1±10%) W
Lift: 14±1 m
Flow: 23 (1±15%)L/min
Ambient temperature: -25~55℃
Medium temperature: 0~50℃
Noise:≦45dB@1m
Protection level: submersible (single body)
Lifespan: >20000H
Customized functions:
PWM speed regulation, 0~5V speed regulation, and FG signal feedback can be realized
Product features:
Brushless motor structure, high-precision rotor, long life, reliable performance
Closed impeller design, higher efficiency, lower power consumption, and superior diving performance
Product applications:
tankless smart toilet flushing, smart toilets, smart bathtubs, and other kitchen and bathroom electrical equipment
